1 Axial Rotator Automatic Welding Rotary Positioner Welding Turntable for Robot

1 Axial Rotator Automatic Welding Rotary Positioner Welding Turntable for Robot

Overview
Recommended Products

Product Description

HP-100/200/300 Positioner.

Designed to give maximum positioning flexbility by using the tilting and rotation of the table to manipulate the workpiece into the appropriate angle for welding or to position accurately for assembly and manufacturing requirements. These very versatile handling tools enable welding to be carried out in the optimum positions to benefit the quality of the work.

Features

 For annular welding, cutting, polishing and assembly.  Easy to set up a small welding center equipped with chuck, tracks, torch holders or stop cone.  DC infinitely variable speed control system.  Rotation time relay function optional.  Welder linked auto welding control function.

1 Axial Rotator Automatic Welding Rotary Positioner Welding Turntable for Robot details

1 Axial Rotator Automatic Welding Rotary Positioner Welding Turntable for Robot manufacture

Specification

Model	HP-100	HP-200	HP-300
Horizontal Capacity	100kgs	200kgs	300kgs
Vertical Capacity	50kgs	100kgs	150kgs
Rotation Speed	0.05-0.5r/min	0.05-0.5r/min	0.2-2.5r/min
Tilt Angle Range	0-90 degree / hand wheel	0-90 degree / hand wheel	0-90 degree / hand wheel
Table Diameter	400mm	400mm	500mm
Height of Table	500mm	500mm	600mm
Table Hole Size	45mm	45mm	90mm
Motor Power	120W	180W	220W
Weight	75kgs	80kgs	110kgs
Applicative Chucks	KD - 300/400	KD - 200 /300/400	KD - 300/400
Input Voltage	1ph 220V 50~60Hz	1ph 220V 50~60Hz	1ph 220V 50~60Hz

Company Profile

Founded in 2000, our company is a professional welding and cutting solutions provider, committed to providing users worldwide with safe, reliable, efficient and economical welding and cutting materials, welding and cutting machines and industrial welding and cutting robots.

FAQ

1. Delivery time:

For stocks order, the delivery time is 3-7days after receiving the payment.
For OEM order, delivery time is 45 days after receiving deposit.

2. Can you provide ODM/OEM service?

Yes we can provide ODM/OEM service.

3. How about quality control about the goods?

We can provide inspection pictures or video for the products if you require.

4. How about the guarantee time?

It's within 1 year after goods is discharged in the destination.

5. why should you buy from us not from other suppliers?
One-stop service for Automatic welding machine, Welding robots, Manual welding and cutting machine equipment, Cold welding machine, Seam welding machine, welding and cutting accessories.

6. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,Express Delivery；
Accepted Payment Currency:USD,EUR,JPY,CAD,AUD,HKD,GBP,CNY,CHF;
Accepted Payment Type: T/T,L/C,PayPal;
Language Spoken:English,Chinese
