Product Name: |
Industrial Heavy Duty MMA ARC500 IGBT Inverter Welding Machine Welder |
||||||
Features |
1. Digital 32-bit chip processor, fast computing speed, agile arc dynamic reflection. 2. The core components adopt industrial-grade IGBT module with high reliability. 3. The actual output current is 500A, the load duty cycle is 60%, and the 5.0 electrode can be welded for 24 hours without interruption. 4. At the same time, it has the functions of anti-electric shock, anti-stick strip, thrust and thermal arc initiation, which can easily realize arc initiation and welding process, and effectively protect the safety of the operators. |
||||||
Input Voltage |
380V 3ph 50/60Hz |
Insulation Class |
H |
Open Circuit Voltage |
70V |
Duty Cycle (40°C) |
60%@500A, 100%@310A |
Welding Current |
20~500A |
Protection Class |
IP21S |
Dimensions |
470X240X430mm |
Weight |
20KGS |
Electrode Diameter |
2.5~6.0mm |
