Product Name: |
MIG350F DC Inverter MIG Welding Machine Welder Solda with Wire Feeder and Trolley no Water Tank |
||||||
Dimensions: |
555×240×445mm |
||||||
Features |
1. Digital display: Variable amperage control with digital meter, for a simultaneous welding current and voltage display.
2. Wire feeder: Capable of loading up to 20KG spool.
3. Arc Stability: Waveform control, for added stability of the arc, even at low currents.
4. Protections: Equipped with temperature, voltage and current sensors for high protection.
5. 440V Tested in production.
6. Generator Friendly
7. PLP: Phase loss protection
8. Protection: Equipped with temperature, voltage and current sensors for high protection.
|
||||||
Input Voltage |
3-380V 3PH 50/60Hz |
Rated Input Current |
28A |
Insulation Class |
H |
Open Circuit Voltage |
67 V |
Duty Cycle (40°C) |
100%@275A, 60%@350A |
Welding Current |
40~350A |
Welding Wire Diameter |
0.6, 0.8, 0.9, 1.0, 1.2mm |
Protection Class |
IP23 |
Dimensions |
555×213×445mm |
Weight |
21KG |
Welder package size |
68*31*56cm |
Wire Feeder package size |
66*43*60cm |
Trolley package size |
111*51*25cm |
