Product Name: |
Heavy Duty 3 Phase Dual Remote Control Generator Friendly AC DC Inverter HF TIG Welder |
||||||
Dimensions: |
550*240*445mm |
||||||
Features |
Phase Loss Protection. Optional trolley and water cooling unit.
High frequency tig mode.
Heavy Duty Cycle.
550V tested in production.
Multi-Waveform output, ac waveforms include square wave, sine wave, triangular wave.
3 phase 380V/400V 415V/440V 50/60Hz.
Remote foot control and wireless remote control.
AC balance (50-85%) control monitors the oxide and helps better cleaning during aluminum welding.
|
||||||
Input Voltage |
3-380V |
Input Current |
25/32A |
Input Power |
13/17KW |
Insulation Class |
H |
Duty Cycle (40°C) |
60%400A; 100%310A; |
No Load Voltage |
67V |
Effective Current |
19/25A; |
Protection Class |
IP23 |
Cooling |
AF |
Welding Current |
10-400A |
Fre.HZ |
50/60 |
Pulse width range % |
5-95 |
Dimensions |
550*240*445mm |
Weight |
27kg |
