TKrobot Welding Torch Cleaning Station Welding Robot Gun Cleaner

TKrobot Welding Torch Cleaning Station Welding Robot Gun Cleaner

Overview
Recommended Products

Product Description

TKrobot Welding Torch Cleaning Station Welding Robot Gun Cleaner manufacture

Specification

Item	Reamer Model	Nozzle (inner dia.) Φd	Contact Tips（outer dia.)Φd
SPZL001063	T300-12-8	13mm	7mm
SPZL000090	T300-12-9	13mm	8mm
SPZL000089	T300-12-10	13mm	9mm
SPZL001064	T300-15-8	16mm	7mm
SPZL000101	T300-15-9	16mm	8mm
SPZL000109	T300-15-10	16mm	9mm
SPZL000099	T300-15-11	16mm	10mm

TKrobot Welding Torch Cleaning Station Welding Robot Gun Cleaner supplier

Item	Values
Air supply pressure	≥0.6Mpa Oil-free compressed air, ≥6 bar
Air supply interface size	8 Quick-plug
Control signal	DC 24V
External system interface	9 pin aviation socket (ex-works standards edition includes the aviation plug, without cable)
Torch cleaning cycle	Approx. 4-5 s
Oil spray volume	Adjustable
Jet cleaning oil capacity	500ml
Wire cutting performance	Max. 2.0mm steel wire
Weight	23kgs

* Solenoids integrated into station stand for improved protection and easy access
* Single point connector for a true plug-and-play torch cleaning solution
* Optimized module stand height for simpler access and easier placement in the weld cell
* Anti-spatter Injector easily adjustable and able to be maintained tool-free
* Future Fieldbus integration available soon

Company Profile

Shanghai Fengling Company, founded in 2000, is a company focusing on professional services in the welding industry. It mainly provides customers with integrated services of welding materials, welding equipment, welding automatic production lines and welding process research and development. Provide technology and services for many landmark projects and well-known enterprises, cooperation projects include (Shanghai Center, Hongqiao Transportation Hub, Jin Mao Tower, China National World Expo, National Convention and Exhibition Center, Scientist Building, etc.), cooperative enterprises (Shanghai Construction Group, MCC Steel Group), more than 20 years of accumulated very rich and valuable professional service experience. Our company has a high-quality welding technology central laboratory, with its own brand TKweld and welding robot TKrobot. At the same time, it cooperates with the world's well-known welding power supply and welding robot brands, welding power supply includes(Lincoln of USA, SAFRA of France, Kemppi of Finland, ESAB of Sweden, OTC of Japan, Panasonic, China Aotai, Megmeet, etc.), and welding robots have four major families in the world (Fanuc, Yaskawa, Kuka, ABB, etc.). FengLing aspires to become an integrated professional technical service company with great influence in the welding industry.

Packing & Delivery

TKrobot Welding Torch Cleaning Station Welding Robot Gun Cleaner details

Standard carton Box, Customized packing available

TKrobot Welding Torch Cleaning Station Welding Robot Gun Cleaner factory

FAQ

Q1: What kind of company are you?
A: We are the real professional welding machines supplier, which has production team, R&D team, sales force and after-sale serviceteam. And we have our own welding robot laboratory for research and to provide free technical training.

Q2:How do you guarantee product quality?
A:We have our own welding laboratory, which not only tests all welding consumables but also provides customers with welding solutions, accumulates a large amount of data experience, and has absolute experience in product quality control.

Q3. Do you have any warranty?
A: Yes, we have. One year warranty for welding torch cleaning station.

Q4. What certification do you have?
A: CE

Q5: What's the package?
A: packing in box

Q6: What is delivery time / lead time ?
A: The goods will be shipped within15-30 days after the receipt of your payment.

Q7: What is your minimum order ?
A: 1pc .

Q8: What is your payment term ?
A:1- 30% down payment for order confirmation, 70% before shipment. 2- 100% at sight LC.
