Product Name: |
Professional Gas Shielded Welding MIG MAG CO2 Welding Welder |
||||||
Dimensions: |
590*302*565mm |
||||||
Features |
1. Digital 32-bit chip processor, fast computing speed, agile arc dynamic reflection. 2. The core components adopt industrial-grade IGBT module with high reliability. 3. The actual output current is 400A, the load duty cycle is 60%, and the 5.0 electrode can be welded for 24 hours without interruption. 4.35mm² cable lengthened to 200 meters, it still can weld 5.0 electrode. 5. At the same time, it has the functions of anti-electric shock, anti-stick strip, thrust and thermal arc initiation, which can easily realize arc initiation and welding process, and effectively protect the safety of the operators. |
||||||
Input Voltage |
380V 3ph 50/60Hz |
Input Current |
39A |
Insulation Class |
H |
Open Circuit Voltage |
80 V |
Duty Cycle (40°C) |
60%@480A |
Welding Current |
60~500A |
Load Voltage |
80 |
Protection Class |
IP21S |
Dimensions |
590*302*565 |
Weight |
42kg |
